Melting Pot

This product is suitable for food, drink, medicine, chemical industry and other industries, such as intermediate buffer, liquid storage, mixing, blending, etc., this product is well stirred, high efficiency, easy to operate. It is a point to use the heat .....





Model:





Motor Power:
Share With:
Details
Video
Parameters
Inquiry
Related Products
Details
INTRODUCTION
The melting pot is an auxiliary euipment for granulator aand coating machine.It is mainly used in compound fertilizer process.By spraying anti caking agent,the agglomeration poblem of compound fertilizer is alleviated.The melting pot is made of stainless steel and can be selected as heating device.This product is suitable for food, drink, medicine, chemical industry and other industries, such as intermediate buffer, liquid storage, mixing, blending, etc., this product is well stirred, high efficiency, easy to operate. It is a point to use the heat source and environmental protection. The top feed inlet is convenient to feed, and the observation hole is simple. The barrel is equipped with liquid level meter to observe the storage of liquid.

WORKING PRINCIPLE
 This machine is made up of frame, shell, mixing system, heating device, measuring system and power distribution cabinet. After the heating system is started, the liquid is input, the position of the liquid surface is observed, the motor of the mixing system is started to drive the rotating blade, so that the temperature of the liquid can be fully mixed to achieve the ideal effect, and it is convenient for the delivery of the metering pump. According to the actual situation, adjust the metering pump knob.

Video
Parameters
Model Driving Power Heating Power Heating Area Metering Pump Power Weight
DYG1.0 XWD5-3kW 18(12)kW 1.7m² ZRJM2-0.8 0.37kW 0.75t
